PowerNode 500

Products

Up to 500kW BESS

Download datasheet Request quote

Back

Output power:

Select location and cooling:

Select battery:

Request quote

50kW500kW1MW

Modular and scalable – now in higher power

From grid connected BESS supporting FCAS, arbitrage and balancing support – to off-grid BESS and SAP, where Pixii delivers smarter microgrid control, remote diagnostics, and future-proof flexibility.

Smarter control with Pixii EMS

The Pixii PowerNode goes beyond energy storage, providing fully autonomous management & control coordination between power sources and loads – ensuring efficient energy distribution, load management, battery optimisation, and data logging with granular detail. All under one cyber secure digital platform fully developed by Pixii engineers in Europe and Australia.

Trusted safety and compliance

Certified to the toughest international standards (UL, IEC, NFPA, AS/NZS & UL9540A). All our systems are tested and validated for safe operation and durability. With more than 2 800 sites installed worldwide, Pixii combines a proven track record and direct support from the Pixii team.

Gain full control with reliable off-grid capability and true independence from grid constraints

Modular, factory-tested design
reduces on-site work and installation costs by over 60%

Scalable and redundant

From 100kW to 10MW – Pixii PowerNode scales seamlessly for use in C&I projects to multi-megawatt utilities. Plug-and-play parallel expansion provides installation flexibility, increases uptime and simplifies maintenance.

Maximum efficiency, lower lifetime cost

With conversion efficiencies up to 98.5% and optimized thermal design, the PowerNode cuts losses and operating expenses. Every kilowatt-hour delivers maximum ROI.

Built for every application

Functionality everywhere – metropolitan network connected community batteries, regional network and SWER line support, microgrid backup, and weak grid, HVDC EV charging. Configurable to suit every application, the Pixii PowerNode with flexible EMS control is your total solution.

Specifications Highlights Typical applications

AC specifications

Grid connection type(1)

IT/TN

Phase config. (grid)

1ph / 3ph

Wiring method

3 ph. 3-wire / 3 ph. 4-wire

AC voltage (-10/+15%)

230V/400V

Nominal frequency (grid)

50/60Hz

Nominal AC current

4x200A

Peak short-circuit current (RMS)

1188A @ 11ms

Nom. cont. AC power (±2%)(2)

500kW

Max. reactive power

500kVAr

Power factor (Cos φ leading)

0.99 / -1~1

THDi (grid connection)

<3%

Off-grid operation support

Yes

Generator backup support

Yes

1. 15 min. 110%, temperature limited 2. The stated power and energy capacities are baseline, or nominal values. Actual performance can vary and may be constrained by several factors, including the state of charge (SoC), state of health (SoH) of the system, as well as thermal conditions.

DC specifications

Max. DC current

4x203A

Nominal DC voltage 3 ph. 3-wire

615V – 950V

Nominal DC voltage 3 ph. 4-wire

650V – 950V

Communication and connectivity

Wired interfaces

Ethernet LAN, RS 485 (Modbus), Digital IO

Internal comm. protocols

CAN bus, Modbus TCP/RTU

External comm. protocols

MQTT

Safety

Ingress protection (IP)

IP55

Overvoltage category (OVC)

III

AC breaker

1000A MCCB 4 pole

DC breaker

4 x 250A MCCB 2 pole

Operating conditions

Operating environment

Outdoor

Thermal management

Fan filter

Acoustic noise 1m distance

<65dB(A)

Operating amb. temp. range(1)

-30 – +55°C

Storage temp. range

-45°C – +70°C

Operating relative humidity(2)

5% – 95%NC

Max. operating altitude(3)

2000m

1) Derating from >45°C 2) Non-condensing 3) Derating >2000m

Physical specifications

Dimensions (HxWxD)(mm)

2300x800x1077

Net. weight (cabinet only)

TBD

Cabinet Weight (@125kW)

300kg

Cabinet Weight (@250kW)

382kg

Cabinet Weight (@375kW)

457kg

Cabinet Weight (@500kW)

499kg

Status indicator (type)

LED

Warranty and compliance

Security and safety standards

GB/T 34120-2017, GB/T 34133-2017, IEC/EN 62477-1, IEC/EN 62116, IEC/EN 62109-1

Grid standards(1)

AS/NZS 4777.2 (AU+NZ), VDE-AR-N 4105 (DE), VDE-AR-N 4110 (DE), VDE-AR-V 0124-100 (DE), VDE-AR-V 4120 (DE), IEC/EN50549-1 Type A & B (EU), EREC G99 Type A & B (UK), EREC G99 Type C & D Upgrade (UK), UNE 217001 (ES), UNE 217002 (ES)

EMC standards

IEC/EN 61000-6-1, IEC/EN 61000-6-2, IEC/EN 61000-6-3, IEC/EN 61000-6-4”

Standard warranty(2)

5 years

1. Designed in accordance with the relevant national and international standards listed above. Certification to specific revisions available on request. Additional local requirements may apply. 2. Warranty terms may vary based on your SLA agreement. Please review the warranty document for details.

Efficiency and performance*

System overload

110%, 550kW

System overload (1min)

120%, 600kW

System overload (150ms)

150%, 750kW

Maximum efficiency

98.5%

Charge/discharge nom. apparent power

500kVA

* Subject to temperature derating

DC microgrid
Black start islanding
Spinning reserve
Droop control

Overload/power: 150% for 180ms 120% for 60 seconds
1 Sec. Frequency Services (FCAS)
Seamless transfer without interruption

Peak shaving
Demand charge reduction
Energy shifting
EV charging

Diesel gensets integration
DC & AC coupled solar
Grid support
